Speed gates : Sweeper-WP

Sweeper-WP

Sweeper-WP is type of speed gate, that can be used outdoors on the areas with increased level of humidity (nearby such facilities as waterparks, swimming pools, reservoirs etc.). It has a waterproof construction.

Sweeper-WP speed gate is a perfect solution where contemporary aesthetics and functionality are required, as well as reliably protected mechanism of speed gate.

Product specifications and complete sets may differ from that shown on the photo.

  • Specifications
  • Datasheet
  • Drawings (pdf/dwg)
  • Manual
Sweeper-WP
Unit dimensions (WxLxH), mm 210x1260x1000
Opening/closing time, sec 0.3/0.6
Passage width, mm 550/900
Locking system ToothLock®
mechanism BMDrive® servo-driven (BLDC)
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated RAL
Top lid Solid glass top
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 12 V
Maximum power consumption, W/pass 160
Mean time to failure, cycles MCBF 10 000 000
Indication DotLights®, RFIDLights®, EdgeLights®
Protective level IP 54


Drawings Sweeper-WP (PDF 1,47 Mb)

Login to get Sweeper .dwg drawing




Login to get Sweeper-WP manual
