TiSO speed turnstile Sweeper-S-HG

SWEEPER-S-HG

Sweeper-S-HG is most compact barrier optical turnstile. It has a slim, elegant design and minimal occupied area while offering widest opening clearance to allow big boxes, trolley, wheelchair, baby stroller or user with big luggage to pass through with comfort. The Sweeper-S-HG turnstile model with full-height swing leaves guarantees a high level of security and a long service life. High leaves not only exclude the possibility of unauthorized passage, but also prevent to transfer of anything above the turnstile, as well as over jumping it. The use of impact-resistant tempered glass guarantees safety and gives a sophisticated modern look. Well-rounded design of the turnstile posts, changeable illumination and expressive indication makes this turnstile usage safe and comfortable for passengers.



● The speed gates have an ultra-modern futuristic design. Our speed gates of this series are ideal for stylish lobby interiors in hotels, banks, office centers, etc;

●BMDrive® Reliable mechanism with powerful BLDC gear motor ensures long term maintenance-free operation;

● The smart self-diagnosing system of mechanism BMDrive® automatically analyzes the system, detects critical malfunctions, and records error log and warnings;

● The BMDrive® mechanism controller is equipped with an OLED display for easy setup and configuration without special programmers, also a full configuration and diagnostics is possible via a USB connector by using a service software for Windows OS;

●Digital control of force and leaf speed in combination with safety sensors prevent a passing person from being struck by a leaf, even in case of an unauthorized passage.

Product specifications and complete sets may differ from that shown on the photo.

  • Specifications
  • Datasheet
  • Drawings (pdf/dwg)
  • Manual
  • Gallery
  • Video
  • Bim objects
Sweeper-S-HG 550 Sweeper-S-HG 900
Unit dimensions (WxLxH), mm 110x1334x1013
Passage width, mm 550 900
Opening/closing time, sec 0.6 0.8
Locking system ToothLock®
Mechanism BMDrive® servo-driven (BLDC)
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated RAL
Top lid Solid glass top
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 12 V
Maximum power consumption, W/pass 160
Mean time to failure, cycles MCBF 10 000 000
Indication DotLights®, RFIDLights®, EdgeLights®
Temperature range, °С +1 / +40


Drawing of Sweeper-S-HG 550+900 (PDF 117 Kb)

Login to get Drawing of Sweeper-S-HG .dwg drawing




Login to get Sweeper manual









Login to get Sweeper-S-HG Bim Objects
