SWEEPER-HG

Brand-new model

Tall version of speed gates model intended for applications where a higher degree of security is required. High swing glass leaves available up to 1800 mm from the floor. It helps to avoid transfer of anything above the turnstile, as well as overjumping it.
Special design allows to arrange even 900 mm passage which can be used for people with special

● The speed gates have an ultra-modern futuristic design. Our speed gates of this series are ideal for stylish lobby interiors in hotels, banks, office centers, etc;

●BMDrive® Reliable mechanism with powerful BLDC gear motor ensures long term maintenance-free operation;

● Robust PinLock® locking system prevents from full leaves opening manually in case of vandalism;

● The smart self-diagnosing system of mechanism BMDrive® automatically analyzes the system, detects critical malfunctions, and records error log and warnings;

● The BMDrive® mechanism controller is equipped with an OLED display for easy setup and configuration without special programmers, also a full configuration and diagnostics is possible via a USB connector by using a service software for Windows OS;

●Digital control of force and leaf speed in combination with safety sensors prevent a passing person from being struck by a leaf, even in case of an unauthorized passage;

● By use of artificial intelligence algorithms and large number of high-precision infrared passage sensors, the speed gates detects and alarms when two people try to pass by one card, pass in the wrong direction and pass without authorization;

● Sensor system allows detecting the passage of person with luggage, arranging a free exit without the need for identification.

Product specifications and complete sets may differ from that shown on the photo.

  • Specifications
  • Drawings (pdf/dwg)
  • Bim objects
  • Gallery
  • Video
  • Datasheet
  • Manual
Unit dimensions (WxLxH), mm Sweeper-HG 550 Sweeper-HG 900
Unit dimensions (WxLxH), mm 190x1440x1500/1800
Passage width, mm 550 900
Open or close speed 0.7 0.9
Locking system ToothLock®
Mechanism BMDrive® servo-driven (BLDC)
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated RAL
Top lid Stainless steel top with glass inserts
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 12 V
Maximum power consumption, W/pass 160
Mean time to failure MCBF 3 000 000 cycles
Indication DotLights®, RFIDLights®, EdgeLights®
Temperature range, °С +1 / +40
