Sweeper-SH
Sweeper-SH is slim, elegant design requires minimal space while providing the widest opening clearance for comfortable passage with wheelchairs, strollers, large boxes, or luggage.
The model with full-height swing leaves ensures high security and long service
life. Tempered glass guarantees safety and adds a modern, sophisticated look. Adjustable illumination, and clear indication make the Sweeper-SH safe and convenient for users.
Product specifications and complete sets may differ from that shown on the photo.
- Specifications
- Datasheet
- Drawings (pdf/dwg)
- Manual
- Video
| Sweeper-SH | ||
| Unit dimensions (WxLxH), mm | 110x435x1013 | |
| Passage width, mm | 550 | 900 |
| Opening/closing time, sec | 0.6 | 0.8 |
| Locking system | ToothLock® | |
| Mechanism | BMDrive® servo-driven (BLDC) | |
| Standard housing | Brushed SS AISI 304 | |
| Available housing | Brushed SS AISI 316 Polished SS AISI 304 Polished SS AISI 316 Powder coated RAL |
|
| Voltage | from the AC (100–240) V, 50/60 Hz from a DC source 12 V |
|
| Maximum power consumption, W/pass | 160 | |
| Mean time to failure, cycles | MCBF 10 000 000 | |
| MTTR, min | < 25 | |
| Indication | DotLights®, RFIDLights®, EdgeLights® | |
