SLIDE

Slide speed gate with folding high gates is stylish original solution for your location that guarantees effective protection of the site.
Slide speed gate could be easily fitted to any location: office centers, banks, hotels etc.
The folding system of Slide gates has a more robust, reliable design compared to existing speed gates on market.
The height of the flaps excludes the possibility of unauthorized passage, and also prevents the transfer of any objects.

Key features

● BMDrive® - Reliable mechanism with powerful BLDC gear motor ensures long term maintenance free operation;

● The safety function of locking system FoldEmLock® prevents the glass leaf breaking in case of vandalism;

● The smart self-diagnosing system of mechanism BMDrive® automatically analyzes the system, detects critical malfunctions, and records error log and warnings;

● The BMDrive® mechanism controller is equipped with an OLED display for easy setup and configuration without special programmers, also a full configuration and diagnostics is possible via a USB connector by using a service software for
Windows OS;

● Digital control of force and leaf speed in combination with safety sensors prevent a passing person from being struck by a leaf, even in case of an unauthorized passage;

● By use of artificial intelligence algorithms and large number of high-precision infrared passage sensors, Slide speed gate detects and sounds the alarm when two people try to pass by one card, pass in the wrong direction and pass without authorization.

Product specifications and complete sets may differ from that shown on the photo.

  • Datasheet
  • Specifications
  • Drawings (pdf/dwg)
  • Manual
  • Gallery
  • Video
  • Bim objects
Unit dimensions (WxLxH), mm Slide 550 Slide 900
Unit dimensions (HxLxW), mm 1500x1432x856/1206
Passage width, mm 550 900
Open or close speed 0.7 1
Blocking system FoldEmLock®
Mechanism BMDrive® servo-driven (BLDC)
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated RAL
Voltage from the AC (100–240) V, 50/60 Hz
from a DC source 12 V
Indication DotLights®, RFIDLights®, EdgeLights®, FloorLights®
Emergency mode Free entry/exit (gates are opened automatically)
Power fail Fail safe (gates could be opened manually — standard)


Slide (PDF 178 kb)

Login to get Slide .dwg drawing




Download material coming soon. It is currently under development.





Download material coming soon. It is currently under development.
