Twix - M

Twix-M turnstile is a robust and reliable model of the tripod turnstile series. This model will efficiently control the entrance even in intensive pedestrian flow mode, making it suitable for heavily used sites like stadiums, industrial plants or factories. Design of this tripod barriers for access control is sleek and elegant, with a choice of housing finishing options it will fit perfectly in both modest interiors as well elegant office buildings. Robust design and high quality materials will ensure reliable operation for years. To overcome the potential problem of crowding in an emergency the Twix M automatic tripod turnstile has a drop arm function.

    Advantages:
  • Bi-directional motorized tripod turnstile with panic / bar drop function;
  • High quality at a cost effective price;
  • Integration with any type of access control and ID systems;
  • Low power consumption;
  • Panic / bar drop function with automatic reset;
  • Whisper quiet, low noise operation;
  • Optional indoor or outdoor housing types;
  • Wide range of accessories;
  • Availability of a back-up battery connection;
  • Complete supply set as a standard.

Характеристики и комплектация товара могут отличаться от показанных на фото.

Unit dimensions (HxLxW), mm
1000x1000x785
Crossing capacity in free access mode, person/min
60
Crossing capacity in single access mode, person/min
25
Passage width, mm
600
Mechanism
Motorized (Triservo-M)
Blocking mechanism
Two electromechanical stop catches (separate locking system)
Emergency mode (when power goes off)
Arm drops when power goes off
Drop arm function
Drop arm function can be activated when power is on Drop arm function activates automatically when power goes off
Fail safe
+ (drop arm)
Standard housing
Brushed SS AISI 304
Available housing
Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated (any RAL up on request)
Voltage
AC (100-240)V, 50/60Hz;
DC source 12 V
Maximum power consumption
55 W
Enclosure rating*
IP 41 – 54
MCBF, cycles
1 500 000
  • Specifications
  • Datasheet
  • Drawings (pdf/dwg)
  • Bim objects
  • Gallery
  • Video
  • Manual
Model Twix - M
Unit dimensions (HxLxW), mm 1000x1000x785
Crossing capacity in free access mode, person/min 60
Crossing capacity in single access mode, person/min 25
Passage width, mm 600
Mechanism Motorized (Triservo-M)
Blocking mechanism Two electromechanical stop catches (separate locking system)
Emergency mode (when power goes off) Arm drops when power goes off
Drop arm function Drop arm function can be activated when power is on Drop arm function activates automatically when power goes off
Fail safe + (drop arm)
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated (any RAL up on request)
Voltage AC (100-240)V, 50/60Hz;
DC source 12 V
Maximum power consumption 55 W
Enclosure rating IP 41 – 54 *
MCBF, cycles 1 500 000
* first figure is standard, all other available upon request.


Twix - M (PDF 1,42Mb)

Login to get Twix - M .dwg drawing




TiSO BIM models are available from BimObject or the NBS National BIM Library.



Login to get Twix - M manual
