TiSO tripod turnstile Onyx-S


Ergonomic design with stylish body lines is the defining feature of this turnstile. The inclined scratch resistant glass top gives this turnstile a futuristic look making it a stylish architectural element to compliment any modern interior.
These turnstiles are equipped with an automatic bi-directional servo-drive mechanism with a robust locking system and are able to operate reliably and efficiently in high traffic flow locations.
This model has a robust hub with stainless steel pods and a fully automatic anti-panic system, where in the case of an emergency, the arms are automatically lowered and users can freely pass through unhindered.
The cabinet tops are made of a scratch-resistant black glass, which allows simple maintenance and long lasting aesthetics. The sleek LED’s follow the lines of the turnstile’s body, and can be both static and dynamic in operation. Additionally the pulsing display indicates the direction of travel through the turnstile. Two RFID readers are integrated under the top glass reader panels, with LED lighting which provides a clear indication for users to present their access control cards. The combination of all of these LED features clearly determines the status of the passage (Green – Access authorised, Red- Access denied and Blue – Standby mode).


Product specifications and complete sets may differ from that shown on the photo.

  • Specifications
  • Datasheet
  • Brochure
  • Drawings (pdf/dwg)
  • Manual
  • Gallery
  • Video
  • Bim Objects
Model Onyx-S
Crossing capacity in free access mode, person/min 60
Crossing capacity in single access mode, person/min 25
Passage width, mm 600
Dimensions (WxLxH), mm 825x790x1075
Mechanism Servo-driven
Blocking mechanism two electromagnetic stoppers (separate locking system)
Emergency mode (when power goes off) fail-safe (lowering the arm)
Drop arm function Activated manually or by command from the access control / fire alarm system in the absence of power, it works automatically, after the appearance of power it returns to its original position
Standard housing Brushed SS AISI 304
Available housing Brushed SS AISI 316
Polished SS AISI 304
Polished SS AISI 316
Powder coated (any RAL up on request)
Tripod hub Cast aluminum with stainless steel arms
Voltage AC (100-240)V, 50/60Hz;
DC source 12 V
Maximum power consumption, W 55
Standard ambient temperature, °C from +1 to +40
Enclosure rating IP41*
MCBF, cycles 5 000 000
