Swing gates

Gate-GS

Gate-GS is a motorised swing gate powered by the next-generation BMDrive® mechanism, developed to deliver smooth, quiet, and reliable operation even in demanding, high-traffic environments. With an extended service life of 10,000,000 MCBF, it provides outstanding durability, minimises maintenance requirements, and reduces the total cost of ownership.
Built-in Wi-Fi connectivity and a dedicated service keypad enable quick configuration, diagnostics, and commissioning, giving service engineers instant access to system settings for faster installation and more efficient maintenance.
Its robust construction, elegant design, and precise 90° gate movement provide secure, comfortable, and efficient pedestrian flow in offices, public buildings, transport hubs, retail facilities, and industrial sites.

Advantages:

Highly reliable BMDrive® mechanism with an extended service life of 10,000,000 MCBF);
Configuration, diagnostics, and parameter adjustment via Wi-Fi, with secure access from a smartphone or tablet;
Dedicated service keypad connection for advanced diagnostics, commissioning, and maintenance;
Provides convenient access for wheelchair users, people with reduced mobility, and trolley traffic;
Ideal complement to turnstiles within integrated access control systems;
Seamless integration with any access control and identification system;
Available in left-hand, right-hand, and double-sided opening configurations;
Fast and durable ToothLock® leaf locking system with selectable HiSecurity and LowNoise operating modes;
BMDrive® safety mechanism protects the glass leaf from damage in the event of vandalism or forced opening;

Product specifications and complete sets may differ from that shown on the photo.

Specifications
Datasheet
Drawings
Manuals
Gallery
Video
Bim objects

Model	Gate-GS (650mm)	Gate-GS (900mm)
Passage width, mm	650	900
Unit width, mm	815	1065
Unit diameter, mm	225
Unit height (with glass), mm	1000
Mechanism	BMDrive® servo-driven (BLDC)
Standard housing	Brushed SS AISI 304
Available housing	Brushed SS AISI 316 Polished SS AISI 304 Polished SS AISI 316 Powder coated RAL
Voltage	from the AC (100–240) V, 50/60 Hz from a DC source 12 V
Maximum power consumption, W/pass	55
MCBF, cycles	10 000 000
Enclosure rating	IP41-54 *
MTTR, min	< 25
Temperature range, °С	+1 / +40
* first figure is standard, all other available upon request.
